Model: JYFPRA80/1000
Filtration Area: 80 square meters
Plate Size: 1000 mm
Total Chamber Volume: 60 Liters
Number of Plates: 49 pcs
Total Weight: Approximately 4968 kg
Motor Power: 5.5 kW
Overall Dimensions (L x W x H): 5500 mm x 1500 mm x 1400 mm
Connection Ports: DN80 and G3/6 inlet and outlet fittings.
The JYFPRA80/1000 is an 80 sqm circular chamber filter press designed for medium-duty continuous operations in small-scale mining and metallurgy plants. It is constructed with robust 1000mm polypropylene plates.
Model: JYFPRA80/1000
Filtration Area: 80 square meters
Plate Size: 1000 mm
Total Chamber Volume: 60 Liters
Number of Plates: 49 pcs
Total Weight: Approximately 4968 kg
Motor Power: 5.5 kW
Overall Dimensions (L x W x H): 5500 mm x 1500 mm x 1400 mm
Connection Ports: DN80 and G3/6 inlet and outlet fittings.
Construction & Operation:
This filter press features a circular chamber design with 1000mm plates. The configuration is engineered for continuous processing in small plant environments. Its overall dimensions are suited for industrial installations requiring reliable, medium-scale dewatering capacity.
