5 m³/h Flow Capacity Bag Filter Housing | DN25 Connection, 0.09㎡ Area
This DN25 single bag filter housing delivers exceptional
performance in minimal space. With 0.09㎡ filtration area and 5 m³/h flow
capacity, it provides reliable solid-liquid separation for demanding
low-flow applications.
Compact Bag Filter Housings Specification
| Filtration area(㎡) | Diameter of inlet/outlet (mm) | Setting of working pressure | Max flow speed (viscosity 1m㎡/s) |
JYSF-3# | Single Bag Filter | 0.09 | DN25 | Normal bag filter≤0.6MPA (Designed pressure 1.0MPA) | 5m³/h |
JYSF-4# | 0.12 | DN25 | 8m³/h |
JYSF-1# | 0.25 | DN40 | 20m³/h |
JYSF-2# | 0.5 | DN50 | 40m³/h |
JYSF-5# | 1 | DN65 | 80m³/h |
DN25 Compact Bag Filter Housings Key Design & Compliance Features
Parallel Multi-Bag Configuration: Houses multiple filter bags in a single pressure vessel, significantly increasing flow capacity and dirt-holding capability compared to single-bag units—ideal for high-demand water treatment.
Drinking Water Compliance: Constructed with 304/316L stainless steel or certified carbon steel with potable water-grade epoxy lining. All wetted surfaces are compatible with drinking water standards.
Full Port Flanged Connections: DN40 to DN200 flanges (ANSI/ DIN standard) ensure easy, leak-proof integration into your existing water treatment pipeline.
Robust Pressure Vessel Design: Engineered as durable filter housings to withstand system operating pressures, providing long-term service life with minimal maintenance.
Factory-Direct Value: Eliminate intermediary markups. As the manufacturer, we provide competitive pricing, custom modifications, and direct technical support.
